10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder

10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder

  • 10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder
  • 10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder
  • 10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder
  • 10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder
10 Wheels SINOTRUK Dump Truck LHD 371 HP 20CBM 30 - 40 Ton HYVA Hydraulic Cylinder
Detail produk:
Place of Origin: China
Nama merek: SINOTRUK HOKA
Sertifikasi: ISO/3C/BV/IFA/SGS
Model Number: ZZ3255N3646B1
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 1 Unit
Harga: USD38000-USD42000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
Kontak
Detil Deskripsi produk
Product Name: Tipper Dump Truck Model: ZZ3255N3646B1
Drive type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.69, 336HP Cargo body: 5600*2300*1500mm
Loading capacity: 30-40tons Transmission: HW15710
Steering: ZF Brand Hydraulic cylinder: Euro brand
Cahaya Tinggi:

heavy dump truck

,

sinotruk howo dump truck

SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder



Description:

SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder

HOKA brand is the Leader of Heavy Duty Truck Industry Driving King On The Road.

The solebar level upgrading of new high strength materials, tensile strength more than 820Mpa. single beam, 300 x 90 x 8,90mm wing width of the frame for the flexural torsional strength greater, chassis performance is more stable, the bearing capacity is better than that of the original frame and reduce the vehicle weight about 100 kilograms.



Electric cab lift system, reduce labor intensity, easy to vehicle maintenance

The application of ergonomics for the latest achievements in design of the cab, comfortable environment, can ensure the occupants full of go;



fully using the latest Weiboke ABS technology upgrades, increased ASR+EBL+TPM in fully meet the basis of European regulations, to ensure the safety of the vehicle, the maximum.ASR - EBL - to avoid skidding; braking force distribution is better; TPM -- Survey of tire pressure changes at any time.

Adopt LED taillight, high brightness and long service life and low failure, night driving safer.



The new EVB engine braking technology is the guarantee of long road vehicle running, effectively control the speed and increase the braking power, reduce brake frequency, reduce wear of vehicle brake and tire, vehicle to improve the service life and traffic safety will make drivers more assured.

The full use of front disc and drum brake, shorten the braking distance, to ensure traffic safety.



The standard tubeless tire has light weight, good balance, low heat, wear resistance, safety and other advantages, because of low rolling resistance, the fuel can be saved about 5%.



Specifications:




SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder
Model ZZ3257N3647B1
Drive Type 6×4
Engine

WD615.69 , 336HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW15710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3600+1350(mm)
Overall dimension 8375×2496×3450(mm)
Cargo body 5600×2300×1500(mm),Bottom:8mm, Side:6mm
The curb weight 12300(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.



Applications:



working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.



Competitive Advantage:



1) The front windshield and the combination of large mirrors to eliminate blind spots, excellent vision;

2) on the sleeper with safety protection net;

3)Electric cab lift system, reduce labor intensity, facilitate vehicle maintenance.

4)low fuel consumption
5) strong enough engine

6)with all kinds of truck model, which can fulfil your requirement
7)the key parts adopt the world's top technology products
8)based on strong technical support and top level technology make the trucks with high

quality and more reliable

9)quick and efficient spare parts supply bring you more convenient

10)Optimized cargo body structure,light weight,high rigidity,large loading capacity

11)Using the high strength steel,it has long service life

12)Optimized the sealing structure has the better sealing effect.

13)Multiple box structures and device selections

14)The intelligent hydraulic control system helps to avoid error operation, it has higher safety and

running efficiency.

15)fast delivery time, we can arange production according to your needs exactly and

quickly

16) professional import and export dealing precedure, make customs clearance more high efficiency

15)competive price, cost-effective
