Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
Product Name: | Oil Tank Truck | Model: | ZZ2167M5227D1 |
---|---|---|---|
Drive type: | LHD 4X4 | Emission Standard: | Euro 2 |
Engine: | WD615.87, 290HP | Tank body capacity: | 8-12CBM |
Cahaya Tinggi: | fuel oil delivery truck,fuel tanker truck |
Military SINOTRUK HOWO Oil Tank Truck 8-12CBM for oil transporting 4X4 LHD Euro2
Description:
Oil Tank Truck SINOTRUK 8-12CBM for oil transportation 4X4 LHD Euro3 190HP
Golden Prince Oil Tank Truck, adopts German Man L2000 Cab technology, and HF7 or HF9 front axle, HC16 driving axles. Chassis drive tyep have 4X2, 6X2, 6X4 and 8X4. The engine power from 266HP, to 420HP.
Our company production of the Oil Tank Truck adopts advanced butt welding technology, the
high pressure gas after the forming of the tank test leak detection, the tank has high
strength, stable center of gravity, vehicle safety and stable; tank welding after shot
blasting pretreatment process, rust, paint adopts advanced baking technology, durable and
beautiful appearance. Independent sub warehouse, packing for different oil products,
chemicals, food, as liquid food truck, chemical liquid truck and insulation liquid
transport vehicle, dangerous goods transport vehicles, the asphalt transport vehicle use.
The Oil tanker is also called mobile fuel trucks, computer refueling vehicle, oil tanker, tanker loading oil, pulling oil, oil truck, edible oil transport vehicle, mainly for oil derivatives (gasoline, diesel oil, lubricating oil and coal tar oil) transportation and storage. According to a variety of gas or oil, and the use of different environment with the oil, pump oil, a variety of oil equipment, put the function. Tanker special part is composed of a tank, PTO, drive shaft, gear pump, pipeline system components. Pipes system is composed of an oil pump, three through four ball valve, two-way valve. Filter pipe.
Specification:
Oil Tank Truck SINOTRUK 8-12CBM for oil transportation 4X4 LHD Euro3 190HP | |
Chassis Model |
ZZ2167M5227D1 |
Drive Type |
4×4 |
Engine |
WD615.87, 290HP |
Cabin |
HW76, with single berh, with A/C |
Transmission |
HW15710(10 forwards & 2 reverses) |
Front Axle |
STR |
Driving Axle |
ST16, 16 Tons |
Clutch |
hydraulically operating with air assistance |
Rim/ Tire |
12.00R20 |
Wheel base |
5200(mm) |
Capacity of tank body |
6-12CBM |
Thickness of tank body |
3mm,With 2 cabin |
Basic setup |
Gear oil pump, flow meter, flash hider, fire extinguisher |
Overall dimension |
8470×2470×3175mm |
The curb weight |
6340(Kg) |
Gross weight |
16000 kg |
Max. speed |
95km/h |
Color |
White, red, green, golden and so on. |
Applications:
The Oil tank truck is mainly used for oil derivatives (gasoline, diesel oil, lubricating oil and coal tar oil)
transportation and storage.
Competitive Advantage:
1) Our company produces the Oil tank truck with advanced butt welding technology, after the forming
of the tank high pressure gas leak detection, the tank has a high intensity, stable center of gravity,
safe and stable vehicle characteristics;
2) with all kinds of truck model, which can fulfill your requirement
3) the key parts adopt the world's top technology products
4) based on strong technical support and top level technology make the trucks with high quality and
more reliable
5) Shot blasting pre treatment process after welding tank, rust, paint adopts the advanced baking technology, durable and beautiful appearance. Independent sub positions,
6) Divided into different oil products, chemicals, food, as liquid food truck, chemical liquid truck,
insulation liquid vehicles, dangerous goods transport vehicles, the asphalt transportation vehicle
7) External sandblasting processing of tank, internal anti-corrosion treatment, Outside surface adopts advanced polyurethane paint, beautiful appearance
8) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,
150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees
flowers and plants
9) competitive price, cost-effective
10) quick and efficient spare parts supply bring you more convenient
11) fast delivery time, we can arrange production according to your needs exactly and quickly
12) professional import and export dealing procedure, make customs clearance more high efficiency
