SINOTRUK INTERNATIONAL HOWO A7 Concrete Mixer Truck 10CBM 371HP 6X4 LHD

SINOTRUK INTERNATIONAL HOWO A7 Concrete Mixer Truck 10CBM 371HP 6X4 LHD

SINOTRUK INTERNATIONAL HOWO A7  Concrete Mixer Truck 10CBM 371HP 6X4 LHD
SINOTRUK INTERNATIONAL HOWO A7  Concrete Mixer Truck 10CBM 371HP 6X4 LHD
SINOTRUK INTERNATIONAL HOWO A7  Concrete Mixer Truck 10CBM 371HP 6X4 LHD
Detail produk:
Place of Origin: China
Nama merek: SINOTRUK HOWO A7
Sertifikasi: ISO/3C/BV/IFA/SGS
Model Number: ZZ5257GJBN3847N1
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 1 Unit
Harga: USD48500-USD49500/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Kontak
Detil Deskripsi produk
Nama Produk: truk pengaduk beton Model: ZZ5257GJBN3847N1
Jenis penggerak: LHD 6X4 Standar emisi: Euro 2
Mesin: WD615.47, 371HP Kapasitas Badan Tangki: 10cbm
Cahaya Tinggi:

Truk Pengaduk Beton Bergerak

,

pengaduk beton yang dipasang di truk

,

Truk Pengaduk Beton 6X4 LHD

SINOTRUK INTERNATIONAL HOWO A7 Concrete Mixer Truck 10CBM 371HP 6X4 LHD



Description:



SINOTRUK INTERNATIONAL HOWO A7 Concrete Mixer Truck 10CBM 371HP 6X4 LHD

The HOWO A7 Concrete Mixer Truck adopts HOWO A7 chassis, equipped with A7-W single berth cabin, exclusively for export is equipped with European 2 or Electronic common

rail, EU and Euro IV SINOTRUK independent research and development of engine, standard

German imported ZF steering, HOWO 10 and 12 gear box,HF9 tons of front axle, HC16 or AC16

rear axle, carrying capacity great to meet the needs of customers.



HOWO A7 Concrete Mixer truck is one kind of famouse brand whch exported to South America and Asia countries, which have more comfortable and advance technology cabin, let them looks more beautiful than HOWO trucks.



The mixing tank body is made of high strength wear-resistant steel plate, cage type mold

are integrally formed to ensure that the flange, sections of the cylinder body and

rolling the coaxial degree and circle beat, to ensure smooth operation of the vehicle.

The tank body adopts the double helix blade, moderate density and taper before the

gateball symmetric stirring plate and tank mouth at the installation of blades and a

material guide vanes, resorted to materials to be more even faster.





Specification:



SINOTRUK INTERNATIONAL HOWO A7 Concrete Mixer Truck 10CBM 371HP 6X4 LHD

Model ZZ5257GJBN3847N1
Drive Type 6×4
Engine

WD615.47 , 371HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering ZF8098 hydraulic steering with power assistance.
Clutch

Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with

air assistance

Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3825+1350(mm)
Overall dimension 8604×2496×3950(mm)
Tank body Capacity

10CBM

The curb weight 12800(Kg)
Gross weight 25000 kg
Max. speed 102km/h
Color White, red, green, golden and so on.




Applications:



It’s suitable for agitating and transiting concrete, for construction site, road repairing and some other

 infrastructure construction business.



Competitive Advantage:



1) Uses the high strength steel plate, long service life.

2) Optimization of the whole structure, low center of gravity, high running efficiency.

3) The leading product technology, complete function, excellent performance, reliable quality, easy to

   operate.

4) Product range is wide, the tank capacity of 6 to 18 cubic meters.

5) Imported hydraulic pump, hydraulic motor and speed reducer.

6) Optimization of body structure, special mold production, beautiful appearance, concrete mixing,

discharge uniformity, low rate of residual.

7) Choose a variety of auxiliary device.

8) Match all concrete mixer truck chassis.

9) based on strong technical support and top level technology make the trucks with high

quality and more reliable
10) competive price, cost-effective
11) quick and efficient spare parts supply bring you more convenient
12) fast delivery time, we can arange production according to your needs exactly and

     quickly

13) professional import and export dealing precedure, make customs clearance more high efficiency
