Place of Origin: | China |
Nama merek: | SINOTRUK |
Sertifikasi: | ISO/3C/BV/IFA/SGS |
Model Number: | 3 Axles 50-80Tons |
Minimum Order Quantity: | 1 Unit |
---|---|
Harga: | Negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on |
Delivery Time: | 20 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 4,000units per month |
Nama Produk: | Truk Trailer Semi Rendah | Model: | 3 As 50-80Tons |
---|---|---|---|
Roda kelima: | # 50, # 90 | Kapasitas loading: | 50-80 ton |
Dimensi Flat: | 13000 * 3000mm | As: | 3X16 ton |
Bahan: | Baja karbon atau baja Mn | Landing gear: | 28T Jost |
Cahaya Tinggi: | Semi Trailer Dump Truck,semi flatbed trailers |
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machines
Description:
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machine
Our company's Low bed semi trailer which exported to so many countries, such as Asia countries, Africa countries, South America countries and so on.
Which is popular used in Mining industry, Construction business and so on.
Specification:
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machines |
|
Model | 3 Axles 60Tons |
Axle |
FUWA brand, 16ton, 2 Sets |
Main beam |
Beam height: 500mm Upper plate: 10mm Double Middle plate: 6 mm Down plate: 12mm |
Dimension of Flat |
13000*3000*6mm |
Material |
Carbon steel or Mn steel |
Gross vehicle weight |
75000kgs |
King pin |
#90 |
Support leg |
JOST Standard 28T |
Suspension |
Normal suspension |
Thickness leaf spring |
10/10/10 |
Tire/Rim |
1200R20, 13pcs, 8.5, 12 pcs |
Brake Chamber |
Standard 6 pcs |
Spare wheel carrier |
2 pcs |
Tool box |
1 pcs |
Electrical System |
Chinese standard 24C lighting system |
Side Maker Lamp |
LED lamp |
Painting |
Polyurethane Paint |
Overall dimension |
16000×2500×3880(mm) |
Color | White, red, green, golden and so on. |
Applications:
Low bed semi trailer for a variety of mechanical equipment, large objects, highway construction equipment, large tanks, power station equipment for various steel transportation.
Competitive Advantage:
1) Our company produces low flat semitrailer divided into flat, concave beam and tire exposed structure, beam adopts flat type or goose neck. The frame is ladder type, the beam cross-section is
I-shaped, has high anti breaking strength and bearing capacity.
2) The main plane of the frame is low, which ensures the smooth transportation, and is suitable for carrying all kinds of engineering machinery, large equipment and steel.
3)Using three axis balance, double axis balance or rigid suspension, the mass balance block is arranged
between the front and rear leaf springs.
4) the key parts adopt the world's top technology products
5)based on strong technical support and top level technology make the trucks with high quality and more
reliable
Kontak Person: Mr. Aaron White
Tel: +86-13210598479
Faks: 86-531-85865823
